Velotric Nomad 2 Electric Fat Tire Bike

Bike Size

Regular / Large

User Height Range

Step-Thru / Regular: 5'2'' - 5'11''

Step-Thru / Large: 5'10'' - 6'5''

High-Step / Regular:5'2'' - 5'11''

High-Step / Large: 5'10'' - 6'5''

Frame

Triple-Butted Aluminum Alloy

Fork

RST Hydraulic suspension 100mm travel with Lock-out, Nutted

Motor Hub

48V, 750W, 90Nm

Battery

Removable 48V, 14.7Ah (705.6Wh), IPX7, Certificated by UL 2271

Cell

Samsung/LG 21700 cell, Certificated by UL 2580

Charger

48V, 3.0A Fast Charger

Display

3.5" Full color, High brightness, Bluetooth, Adjustable angle

Sensor

Torque and Cadence Sensor

USB Port

USB Type-C phone charge

Throttle Assist

Trigger-control, removable

Pedal Assist

3 Riding Modes x 5 PAS Levels

Walk Mode

2.9 MPH

Front Light

Light sensing 130 Lux /500 LM high-output integrated LED, adjustable angle

Rear Light

Braking Indicator, turn signal, rear light steady/flash, integrated with rear rack

*A 187-lb rider using PAS 1 in Eco mode on flat roads.

Max Speed (Default)

20 MPH

Max Speed Adjustable Range

12~28 MPH

Class

1/2/3

Throttle Range

45 Miles

Pedal Assist Range

65 Miles

Chainrings

48T

Crankset

Aluminum Alloy, 165mm

Cassette

11-40T

Chain

8-speed

Rear Derailleur

SHIMANO 8-speed

Shift Lever

SHIMANO 8-speed

Brake

Tektro Hydraulic Disc Brake

Rotors

203mm Front/180mm Rear

Brake Levers

Aluminum Alloy, with power cutoff

Rims

Aluminum alloy

Front Hub

Aluminum alloy, nutted

Tire

KENDA 26x4.0" eBike puncture-resistant tires

Handlebar

Aluminum Alloy, Φ31.8mm, 680mm(R)/700mm(L)

Grips

Durable ergonomic grips, lockable

Stem

Adjustable, Aluminum Alloy, Φ31.8mm, 60mm(R)/90mm(L)

Saddle

VELOTRIC comfort ergonomic seat

Seatpost

Aluminum Alloy, Φ30.9mm, Suspension

Clamp

Aluminum Alloy, quick release

Fenders

Front and rear full coverage

Rear Rack

MIK HD Compatible Alloy

Pedals

Plastic

Kickstand

Aluminum Alloy, included, rear mount

Bike Weight

75lbs

Max Bike Load

505lbs

Rear Rack Load Capacity

66lbs

UL Certification

UL 2849

ISO Standard

ISO 4210
